ResinLab EP965 Epoxy Encapsulant Black 400 mL Cartridge

Part number: EP965 BLACK 400ML
ResinLab EP965 Epoxy Encapsulant Black 400 mL Cartridge

Please contact your Ellsworth Customer Service Representative to confirm availability and delivery time.

Call Us

Call Us
Contact customer service at 888-458-0554.

Email Us

Email Us
Email our quotes team.

ResinLab EP965 Black is a two component, room temperature or heat curing, unfilled epoxy encapsulant that is used for medium castings, bonding with most materials, and filling voids. It is electronic grade, semi-rigid, free flowing, and has good air release and wetting properties. It is resistant to bases, acids, water, and most organic solvents. 400 mL Cartridge.

ResinLab EP965 Black is a two component, room temperature or heat curing, unfilled epoxy encapsulant that is used for medium castings, bonding with most materials, and filling voids. It is electronic grade, semi-rigid, free flowing, and has good air release and wetting properties. It is resistant to bases, acids, water, and most organic solvents. 400 mL Cartridge.
Typical Use: Designed for medium sized castings.
Chemical Composition: Epoxy
Color: Black
Components: 2 part
Cure System: Room Temperature/Heat
Cure Time: 24h @ 25 °C; 1h @ 65 °C; 20min @ 100 °C; 15min @ 110 °C
Dielectric Strength: 410 V/mil
Elongation: 5%
Flash Point: Part A: 249 °C; Part B: >100 °C
Hardness: 80 D
Mix Ratio: 1:1 by volume; 1.17:1 by weight
Service Temperature: -40 to 150 °C
Shear Strength: 1,200
Specific Gravity: Part A: 1.16; Part B: 0.97; Mixed: 1.07
Tensile Strength: 8,500 psi
Thermal Conductivity: 0.1 W/mK
Viscosity: Part A: 16,000; Part B: 9,000; Mixed: 14,000
Volume Resistivity: 8 x 10^14 ohm-cm
Working Time: 15 to 20min
