Part number: EP1340 BLACK 400ML
Please contact your Ellsworth Customer Service Representative to confirm availability and delivery time.
ResinLab EP1340 Black is a two component, room temperature or heat curing, flame resistant epoxy casting system that is used for bonding to most materials and filling voids. It is semi-rigid, free flowing, has good wetting and air release. It is resistant to salt solutions, water, organic and inorganic solvents. 400 mL Cartridge.
| Typical Use: | It has good wetting and adhesion to most surfaces and is free flowing to penetrate voids and give good air release. |
| Chemical Composition: | Epoxy |
| Color: | Black |
| Components: | 2 part |
| Cure System: | Room Temperature/Heat |
| Cure Time: | 24 to 48h @ 25 °C; 2h @ 60 °C; 30min @ 100 °C |
| Dielectric Strength: | 513 V/mil |
| Elongation: | 9% |
| Flash Point: | >93 °C |
| Hardness: | 85 D |
| Mix Ratio: | 1:1 by volume; 1.11:1 by weight |
| Service Temperature: | -40 to 150 °C |
| Shear Strength: | 1,300 |
| Specific Gravity: | Part A: 1.37; Part B: 1.23; Mixed: 1.30 |
| Tensile Strength: | 1,300 psi |
| Thermal Conductivity: | 0.22 W/mK |
| Viscosity: | Part A: 12,000; Part B: 16,000; Mixed: 13,500 |
| Volume Resistivity: | 1.51 x 10^14 ohm-cm |
-
-
Part #: EAD400PS-11/21 -
-
-
